Optoisolators - Triac, SCR Output
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | OutputType | ZeroCrossingCircuit | NumberofChannels | Voltage-Isolation | Voltage-OffState | StaticdV/dt(Min) | Current-LEDTrigger(Ift)(Max) | Current-OnState(It(RMS))(Max) | Current-Hold(Ih) | TurnOnTime | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP160G(TPR,U,F)OPTOISOLATOR 2.5KV TRIAC 6MFSOP |
2,469 | - |
|
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | Triac | No | 1 | 2500Vrms | 400 V | 200V/µs | 10mA | 70 mA | 600µA (Typ) | 30µs | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount |
|
MOC3009ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
3,153 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 250 V | - | 30mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
MOC3020ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
2,359 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 400 V | - | 30mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
MOC3023ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
2,337 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 400 V | - | 5mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
MOC3011ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
2,607 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 250 V | - | 10mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
MOC3010ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
2,025 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 250 V | - | 15mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
MOC3021ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
2,305 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 400 V | - | 15mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
MOC3022.300ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
3,450 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 400 V | - | 10mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
MCP3022.300ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
2,336 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 400 V | - | 10mA | - | 200µA | - | - | 60 mA | - | Through Hole |
|
|
MOC3022ISOL 5.3KVRMS 1CH TRIAC OUT 6DIP |
3,329 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | No | 1 | 5300Vrms | 400 V | - | 10mA | - | 100µA | - | - | 50 mA | - | Through Hole |
|
|
4N39OPTOISOLATOR 5.3KV SCR 6DIP |
3,638 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 200 V | 500V/µs | 30mA | 300 mA | 1mA | 50µs (Max) | 1.1V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
4N40OPTOISOLATOR 5.3KV SCR 6DIP |
2,200 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 400 V | 500V/µs | 14mA | 300 mA | 1mA | 50µs (Max) | 1.1V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
H11C1OPTOISOLATOR 5.3KV SCR 6DIP |
2,089 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 200 V | 500V/µs | 20mA | 300 mA | - | - | 1.2V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
H11C2OPTOISOLATOR 5.3KV SCR 6DIP |
3,842 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 200 V | 500V/µs | 20mA | 300 mA | - | - | 1.2V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
H11C3OPTOISOLATOR 5.3KV SCR 6DIP |
2,946 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 200 V | 500V/µs | 30mA | 300 mA | - | - | 1.2V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
H11C4OPTOISOLATOR 5.3KV SCR 6DIP |
3,205 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 400 V | 500V/µs | 20mA | 300 mA | - | - | 1.2V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
H11C5OPTOISOLATOR 5.3KV SCR 6DIP |
3,185 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 400 V | 500V/µs | 20mA | 300 mA | - | - | 1.2V | 60 mA | -55°C ~ 100°C | Through Hole |
|
|
H11C6OPTOISOLATOR 5.3KV SCR 6DIP |
2,311 | - |
|
Datasheet |
Tube | - | Obsolete | SCR | No | 1 | 5300Vrms | 400 V | 500V/µs | 30mA | 300 mA | - | - | 1.2V | 60 mA | -55°C ~ 100°C | Through Hole |
.JPG)
|
TLP3063SCFOPTOISOLATOR 5KV TRIAC 6DIP 5L |
3,997 | - |
|
Datasheet |
Tube | - | Obsolete | Triac | Yes | 1 | 5000Vrms | 600 V | 200V/µs | 5mA | 100 mA | 600µA (Typ) | - | 1.15V | 50 mA | -40°C ~ 100°C | Through Hole |
|
MOC3020S-TA1OPTOISOLATOR 5KV TRIAC 6SMD |
3,056 | - |
|
Datasheet |
Tape & Reel (TR) | MOC302x | Active | Triac | No | 1 | 5000Vrms | 400 V | 1kV/µs | 30mA | - | 250µA (Typ) | - | 1.15V | 50 mA | -40°C ~ 100°C | Surface Mount |
